MEGA CITY 45 EASY REACH

MEGA CITY 45 EASY REACH:

The equipment Mega City Easy Reach,underlift boom 45T capacity,Helper frame adpated and mounted with optimized overhang dimensions.Hydraulic boom arm elevation (40°),single extension(double in option) and Easy reach telescope with tilting correction (-7°)joined to a double sequenced extension.

Predisposition and chassis base required:

• Chassis advised 6x4/8x4 with a GVWR:from 26000 KGS
• Wheelbase chassis mini required:5500 mm
• Power take off required and mounted:80m.kg and std ZF 4 holes.
• Electrical connection rear plug mounted.

Components included into Mega City 45 base:

• Pistons hydraulic pump high quality.
• Rear hydraulic anchorage spades.
• Elecro hydraulic valve block drived by proportionnal radio 12 functions.
• Hydraulic tank with spin-on filter.
• Grid heavy truck.
• Tools batch,Fork holders,forks,fork holder cross bar,etc...
• Tow bar into his tunnel case stored.
• Tow traction eye for semi trailer.
• Link cross member between rear anchorage poles for tow bar.
• Red RAL 3020 Standard color of the boom.
• Rear overhang shortening, subframe fixing on chassis, hydraulic and pneumatic connections. Tests under load.

To this Mega City 45 base around 80 options are available,all hydraulics connections,pneumatics and electricals are made,the equipement is checked and tested under load before delivery when all functionality will be showed you.(made in France)
